SMA11 = Standard flow body, Motor Automatic reset, Normally Closed shut-off. The most commonly specified Maxon EM gas valve. Opens when energized; closes in <1 second when de-energized (power lost or safety circuit opens). Automatic reset means the valve reopens automatically when power is restored and the flame safeguard sequences through a new ignition trial. Used on most industrial furnace and oven gas trains. Available in 3/4" through 6" pipe sizes with suffix codes for solenoid type, voltage, and switch packages per your application requirements.
| Base Model | Pipe Size | DN (metric) | Reset | Function |
| 075SMA11 | 3/4" | DN20 | Auto | Shut-off (NC) |
| 100SMA11 | 1" | DN25 | Auto | Shut-off (NC) |
| 125SMA11 | 1-1/4" | DN32 | Auto | Shut-off (NC) |
| 150SMA11 | 1-1/2" | DN40 | Auto | Shut-off (NC) |
| 200SMA11 | 2" | DN50 | Auto | Shut-off (NC) |
| 250SMA11 | 2-1/2" | DN65 | Auto | Shut-off (NC) |
| 300SMA11 | 3" | DN80 | Auto | Shut-off (NC) |
| 400SMA11 | 4" | DN100 | Auto | Shut-off (NC) |
| 600SMA11 | 6" | DN150 | Auto | Shut-off (NC) |
Note: Base model numbers shown. Full part number includes suffix codes for solenoid, voltage, and switch options — always order by complete nameplate model number. Multiple 150SMA11 configurations available; other sizes available to order. Call (901) 458-2000 for availability and lead time.
3/4" to 6" Pipe
Auto Reset
Normally Closed
Closes <1 Second
FM · CSA · UL · CE
Up to 200,000 Cycles
