Honeywell M9484F1007 Modutrol Motor, 24 Vac

Honeywell

No reviews yet Write a Review
SKU:
M9484F1007
$1,485.56
Trust Section Preview — Memphis Control Center

Have a question?

Our combustion & controls team is ready to help

Trusted transactions Built on trust. Backed by security.
Free same-day shipping 10,000+ SKUs in stock. Always free.
Real people. Ready to help. We pick up the phone — every time.
Hassle-free returns Guaranteed peace of mind.
$1,485.56

Description

Honeywell M9484F1007 Proportional Modutrol IV Motor, 24 Vac, 150 lb-in Torque, 2 Auxiliary Switches, Adjustable Stroke Overview The Honeywell M9484F1007 is a reversing, proportional Modutrol IV motor designed for precise control of burner firing rate valves, dampers, and other auxiliary equipment in commercial and industrial oil or gas burner systems. It is a reliable replacement for the M941A, C, and D series motors, offering enhanced vibration resistance and flexible stroke settings to optimize burner performance. Key Features Voltage: 24 Vac operation, compatible with standard burner control systems. Torque: Powerful 150 lb-in torque suitable for heavy-duty valve and damper actuation. Adjustable Stroke: Field-adjustable stroke settings of 90° (factory default) or 160° to match various application needs. Auxiliary Switches: Two built-in auxiliary switches set at 7° and 80° for additional control and feedback functions. Timing: 30 seconds for 90° stroke, 60 seconds for 160° stroke, ensuring smooth, precise positioning. Shaft: Double-ended 3/8" shaft design for versatile mounting and connection. Durability: Vibration-resistant electronic drive circuit designed for rugged commercial and industrial environments. Operating Temperature: Reliable performance within a broad range from -40°F to 150°F ambient temperature. Technical Specifications Specification Details Voltage 24 Vac Torque 150 lb-in Stroke (Adjustable) 90° (factory default) / 160° Timing 30 sec (90°), 60 sec (160°) Shaft Type Double-ended, 3/8" diameter Auxiliary Switches 2 switches (7° and 80° settings) Power Consumption 15 Watts Ambient Temperature -40°F to 150°F   Applications Commercial and industrial oil or gas burner systems. Modulating burner firing rate valves and damper controls. Auxiliary equipment requiring proportional motor control with feedback switches. Replacement for Honeywell M941A, C, and D series motors.

Extra Information

Brand:
Honeywell
