Bell & Gossett 106190 Series 100 BI Circulator Pump Pump - 1/12 HP, Flanged Cast Iron & Bronze Impeller

Bell & Gossett

No reviews yet Write a Review
SKU:
106190
$828.33
Trust Section Preview — Memphis Control Center

Have a question?

Our combustion & controls team is ready to help

Trusted transactions Built on trust. Backed by security.
Free same-day shipping 10,000+ SKUs in stock. Always free.
Real people. Ready to help. We pick up the phone — every time.
Hassle-free returns Guaranteed peace of mind.
$828.33

Description

Bell & Gossett 106190 – Series 100 BI Circulator Pump, 1/12 HP, 115V, Flanged, Cast Iron with Bronze Impeller Product Highlights Motor: 1/12 HP, 1725 RPM Voltage: 115V, Single Phase, 60 Hz Connection Type: Flanged x Flanged (Fits 3/4", 1", 1-1/4", 1-1/2" flanges) Max Flow Rate: 33 GPM Max Head: 8 ft Material: Cast Iron Body with Bronze Impeller Max Pressure: 125 PSI Max Temperature: 225°F Built-In Overload Protection Product Description The Bell & Gossett 106190 Series 100 BI Circulator Pump is a durable, oil-lubricated, three-piece circulator designed for quiet, efficient operation in residential and light commercial hydronic heating systems. This model features a cast iron pump body with a bronze impeller, delivering long-lasting, corrosion-resistant performance. This pump offers field-serviceable components, including a replaceable shaft, bearing assembly, and mechanical seal. Its built-in thermal overload protection adds extra safety during operation. With a performance curve that supports up to 33 GPM at 8 feet of head, it’s ideal for low-pressure hot water recirculation and zone pumping. Note: Not suitable for potable water applications. Key Features Reliable Bell & Gossett Series 100 performance Oil-lubricated, field-serviceable motor design Cast iron construction with bronze impeller for enhanced durability Compatible with multiple flange sizes: 3/4", 1", 1-1/4", and 1-1/2" Thermal overload protection built-in Easy installation with flanged connections Low maintenance with quiet operation Technical Specifications Attribute Value Model Number 106190 Series 100 BI Horsepower 1/12 HP Voltage 115V Amperage 1.75 A RPM 1725 Frequency 60 Hz Phase 1 Max Flow 33 GPM Flow Range 0–33 GPM Max Head 8 ft Head Range 0–8 ft Max Temperature 225°F Max Pressure 125 PSI Material – Body Cast Iron Material – Impeller Bronze Connection Type Flanged x Flanged Compatible Flange Sizes 3/4", 1", 1-1/4", 1-1/2" Application Hydronic Heating Circulation Potable Water Rated No Ā

Extra Information

Brand:
Bell & Gossett
