Honeywell C6097A3004 Pressure Switch, Auto Reset, 0.4" to 5" W.C, 1/4" NPT (Breaks Circuit on Pressure Fall)
Overview
The Honeywell C6097A3004 is a diaphragm-actuated pressure switch designed for positive-pressure or differential-pressure systems to sense gas or air pressures. It provides reliable safety-limit control for natural gas, liquid propane (LP), or air systems with an auto-reset function.
Key Features
-
Pressure sensing range: 0.4" to 5" W.C.
-
Maximum pressure rating: 0.16" W.C.
-
Switch action: Breaks circuit on pressure fall
-
Auto reset operation for continuous system monitoring
-
Diaphragm-actuated safety-limit switch suitable for gas and air applications
-
Can be wired to activate alarms
-
Lockout available with manual reset and recycle options (lockout models have external reset button)
-
Removable transparent cover protects scaleplate and adjusting knob
-
Pipe tappings allow for selection of positive pressure or venting connections (NPT mount only)
-
Available in 1/4" NPT or flange mount for direct mounting to Honeywell Integrated Valve Train
-
Optional switch position indicator lamp available
-
Surge orifice and integral vent limiter included on all models
-
IP54 enclosure for environmental protection
Specifications
| Specification | Details |
|---|---|
| Switch Operation | Auto Reset |
| Switch Action | Break on pressure fall |
| Pressure Range | 0.4" to 5" W.C |
| Maximum Pressure | 0.16" W.C |
| Mounting | 1/4" NPT or flange mount |
| Application | Natural gas, LP gas, air |
