Description
103401LF NBF-36 Bronze Circulator Pump – 1/6 HP, 3-Speed, Lead Free, 115V
The 103401LF NBF-36 is a durable bronze circulator pump designed for heating applications, featuring a robust 1/6 horsepower motor and three-speed settings. Its lead-free bronze construction ensures reliability and compliance with lead regulations. With flanged connections and a maximum pressure rating of 150 PSI, this pump delivers efficient circulation with a maximum flow rate of 36 GPM and a max head of 34 feet.
Key Features
-
Lead-free bronze construction for durability and safety
-
1/6 horsepower motor with 3-speed operation for flexible performance
-
Flanged inlet and outlet connections for secure and easy installation
-
Designed for heating applications with max temperature up to 225°F
-
High flow capacity with up to 36 GPM and head up to 34 ft
-
Single-phase 115V power supply, 60 Hz operation
-
Compact and reliable with 3200 RPM motor speed
Technical Specifications
| Parameter | Details |
|---|---|
| Material | Lead-Free Bronze |
| Horsepower | 1/6 HP |
| Pump Type | 3-Speed Circulator Pump |
| Application | Heating |
| Voltage | 115 V, Single Phase |
| Frequency | 60 Hz |
| Max Pressure | 150 PSI |
| Max Temperature | 225°F (107°C) |
| Flow Range | 0 – 36 GPM |
| Max Flow | 36 GPM |
| Head Range | 0 – 34 ft |
| Max Head | 34 ft |
| RPM | 3200 |
| Amperage | 2.3 A |
| Connection Size | Flanged x Flanged: - 1-1/4" - 3/4" - 1-1/2" |
Ideal Applications
-
Residential and commercial heating circulation
-
Hydronic heating systems
-
Boiler loop circulation
-
Hot water recirculation
